STYLE
Modern
WEIGHT (KG)
182
FUEL
Wood
CONNECTION DIAMETER (MM)
200
CONNECTION PLACE
on top or rear + possible to convert in 45°
NOMINAL OUTPUT (KW)
15
MINIMAL OUTPUT (KW)
5
MAXIMUM PERFORMANCE (KW)
kW17
CAPACITY (M³)
300
EFFICIENCY
76,00%
CO EMISSIONS (13% O2)
0,1
DUST PARTICLES (MG/NM³)
20
COMBUSTION FLOOR
Refractory bottom with ash hatch
TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K)
268
NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³)
97
SEASONAL SPACE HEATING ENERGY EFFICIENCY (%)
66
DIRECT HEAT OUTPUT (KW)
15
INDIRECT HEAT OUTPUT (KW)
0
TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL
single stage heat output, no room temperature control
