CONNECTION DIAMETER (MM) 150
HEIGHT FLUE (MM) 645
CONNECTION PLACE on top or rear
NOMINAL OUTPUT (KW) 12
MINIMAL OUTPUT (KW) 4
MAXIMUM PERFORMANCE (KW) kW14
CAPACITY (M³) 240
EFFICIENCY
80,00%
CO EMISSIONS (13% O2)
0,06
DUST PARTICLES (MG/NM³)
39,5
COMBUSTION FLOOR
Refractory bottom with ash hatch
MINIMUM PRESSION
12
FLUE GAS VOLUME (G/S)
10,4
LENGTH OF LOGS (CM)
55
SECOND COMBUSTION
Yes
ASH TRAY
Inclusive
HEAT SHIELD
Optional
OUTSIDE AIR
Inclusive
AVAILABLE IN COUNTRIES
Australia
TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K)
270
NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³)
46
SEASONAL SPACE HEATING ENERGY EFFICIENCY (%)
70
DIRECT HEAT OUTPUT (KW)
12
INDIRECT HEAT OUTPUT (KW)
0
TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL
single stage heat output, no room temperature control
